Easy to Install
Convert your bike into an eBike in 4 Steps
- If your Original Tire’s width was in the 1.5-1.95 Inch range. You should have no problems Installing the conversion wheel.
- Please refer to the picture to make sure that the washers are installed in the correct order.
- The lining for the wheel is Pre-Installed, so you only need to put on the inner tube and wheel
- Install the tires to roll in the same direction as the brake disc.
- Finally, check that the tire spins freely without touching the frame or brakes causing extra friction.
-
You can choose to use the bike without the throttle (required in some EU countries), but if you wish to use the throttle, please remove the grip from the handle and Install the throttle on the left or right side of the handlebar.
-
Install the Display. Please note that the power button is on the display's right side. Install the Headlight and Rear light. Various fixing gear such as spacers, supports, nuts, and bolts are included in the kit.
-
Install the Break sensor. Please check that the condition of the brake cable is in good condition and that the threads are straight. The sensor can be installed near the break or the handle. Please note that the sensor arrow needs to point in the direction where the handle is.
-
Install PAS. Remove the left pedal crank with the tool included in the kit and add the PAS. Reinstall the crank.
-
For the Tube battery, just screw it to the existing holes on the downtube. Check that there's enough space for the battery and the cables below.
-
For the Rack battery, please remove the existing one and replace it with the one included in the kit.
-
After installing the Tube or Rackmount, just slide the battery in place and lock it.
-
There's an external controller box/bag included in the kit. You can place it on the frame itself like the top tube.
-
Please connect the cables and use the included ties and wrapping to fix them in place.
